Flex2Fit multi-use thin brick formliner
For casting thin brick into precast and tilt-up panels, pour after pour.
Embedded thin brick on Flex2Fit. Advanced Formliners.
Flex2Fit models.
From the current Flex2Fit spec sheets.
| Model | Bond | Sheet size | Vertical joint | Horizontal joint | Joint height | Spec sheet |
|---|---|---|---|---|---|---|
| F2F1000 | Half running bond modular, textured cove joint | 48" w x 32" h (10.67 SF) | 5/16" to 7/16" | 5/16" to 7/16" | 1/4" | PDF ↓ |
| F2F1000+ | Half bond modular | 48" w x 42.67" h (14.22 SF) | 3/8" | .416" | 1/4" | PDF ↓ |
| F2F1750XL | Stacked bond modular | 48" w x 42.67" h (14.22 SF) | 3/8" | .416" | 1/4" | PDF ↓ |
| F2F4750XL | Stacked bond Norman | 48" w x 42.67" h (14.22 SF) | 3/8" | .416" | 1/4" | PDF ↓ |
Patents
- US 8,852,724 B2, Bridge member spanning formliner joint. In force.
- US 8,888,067 B1, Thermoplastic liner for casting textures and objects into poured wall. Expired.
Flex2Fit specifications.
| Use | Multi use; the same liner takes the next panel |
|---|---|
| Brick | Seals around brick that varies in size, shape and texture within a range |
| Ledge | None |
| Joint profile | Raked, concave, vee and more |
| Accessories | Corners, returns, arches and coursing parts, indexed to the brick |
Flex2Fit work.
-
Varied brick faces with clean joints. -
Panel with a window opening, on site. -
Brick arch and pier, Kyle Field, Texas A&M.
Samples and spec support
Send us the project details and we will get the right liner sample, the technical data and specification support back to you.
Writing the section yourself? Write a specification: six steps, and it comes back by email as a Word file.
